Evidence in Camera Vol 2 1943 03 15 nr 11 (PDF)

$7.95

Description

Evidence in Camera

Volume 2, Number 11, March 15th, 1943

Issued by Air Ministry (A.C.A.S.I.); printed by C. & E. Layton Ltd, London, E.C.4

28 pages scanned

  • Keep It Dark Cartoon: A humorous H. Hunter illustration shows an airman and his companion wheeling a “invalid” through the park while warning readers to keep gossip-gleaned information secret.
  • Attack on Rennes Naval Depot: An aerial photo captures bombs from a dusk Mosquito raid bursting on the Naval Stores Depot at Rennes.
  • Result of the Rennes Attack: A follow-up reconnaissance photo outlines the large area of blast and high-explosive damage caused by the raid.
  • Fortresses Above Cloud, Wilhelmshaven: Four U.S.B.C. Fortress bombers fly in formation above dense cloud during an unescorted daylight raid.
  • Fortress Over Wilhelmshaven: A single Fortress is seen threading through heavy cloud cover that obscured much of the port and hampered bomb-aiming.
  • Liberator Over Myitnge Bridge: A U.S.A.A.F. Liberator is pictured above the winding river during a successful attack on the Myitnge railway bridge in Burma.
  • Myitnge Bridge Direct Hit: A close-up shows a 150-ft span of the bridge knocked into the river by a direct hit.
  • Myitnge Bridge Under Repair: A photo taken a week later shows Japanese workers repairing the damaged span.
  • Morlaix Viaduct Damage: Reconnaissance imagery shows the railway viaduct still out of action nearly a month after sustaining direct hits, with track removed for repair.
  • Night Attack on St. Nazaire: A night photograph shows the streaking light trails of a heavy Bomber Command raid on the port.
  • Nazaire Aftermath: Smoke from fires still burning the day after the raid rises over the town and dock area, with U-boat shelter and rail damage visible.
  • Camouflaged Oil Tanks at Zeebrugge: Twelve fuel tanks have had their tops linked together with light timber-toned material to reduce their visibility from the air.
  • Camouflage Netting at Hoeksken: Netting disguises the roadways and sidings serving a buried oil storage depot on the Ghent/Terneuzen Canal.
  • Camouflaged Shell Depot at Ghent/Evergem: Two tank groups at the depot have been “mounded” and netted to blend with the surrounding sheds.
  • Treptow Petrol Tanks Before Camouflage: The exposed tanks of the Olex D. Petroleum Depot in Berlin are shown prior to any concealment work.
  • Treptow Petrol Tanks After Camouflage: The same tanks have since been roofed over to resemble an ordinary building with square roof-lights.
  • Bordeaux Railway Facilities: An annotated aerial view labels the goods depots, sidings, and junctions of Bordeaux’s rail network.
  • Bordeaux on the River Garonne: A wider view highlights Bordeaux as the lowest bridging point on the Garonne and the hub of the regional rail system around Gare St. Jean.
  • Spezia Port Layout: An annotated photo identifies the commercial port, naval outer harbour, and seaplane base at Spezia, Italy.
  • Damaged Cruiser Bolzano at Spezia: The torpedoed cruiser Bolzano is shown missing part of her funnel and engine casing alongside a Regolo-class cruiser missing part of her forecastle.
  • Bolzano Repair Operation: A later photo shows the unfinished Regolo-class hull moved alongside the Bolzano so its forecastle section can be transferred to speed repairs.
  • Railway Guns Near Zeebrugge: Heavy railway guns on large turntables are shown with their flak defences, trenches, and a suspected dummy turntable.
  • Railway Guns at Narvik: Two of four tarpaulin-covered railway guns sit on reinforced firing points beside support wagons.
  • German Platform Railway Guns: A ground-level photo shows similar railway guns of the German platform type, which are not mounted on turntables.
  • Wireless-Controlled Target Range: An ex-battleship target ship is shown under tow within a relay-equipped practice range.
  • Target Ship Zahringen at Kiel: The former battleship Zahringen, believed used for target practice, is photographed at Kiel.
  • Zahringen and Control Ship at Swinemünde: The Zahringen lies alongside her wireless control vessel, an ex-torpedo boat, which regulates her speed and course.
  • Target Ship Hessen at Swinemünde: The target ship Hessen is moored with her own ex-torpedo-boat control ship alongside.
  • Ju 290 and Ju 90 at Tempelhof: A new four-engined Junkers Ju 290 transport is seen parked beside an older Ju 90 for comparison.
  • Further Ju 290s at Tempelhof: Two more Ju 290 transports are photographed on the airfield at Berlin/Tempelhof.
  • Ju 290 at Algiers/Maison Blanche: A Ju 290 is pictured alongside a Bloch 220 at the Algiers airfield in 1942.
  • Ju 290s at the Dessau Junkers Factory: Several Ju 290s are seen with Ju 86Ps outside a flight hangar at the manufacturer’s plant.
  • Norwegian Coastal Battery: Faint tracks across rocky terrain reveal the position of a four-gun coastal battery that is otherwise well concealed.
  • Krefeld Flak Batteries: Two six-gun heavy flak batteries near Krefeld demonstrate good track discipline, with only narrow paths linking crew quarters to the guns.
  • Close-Up of Krefeld Flak Position: A tighter view of one battery shows the gun pits and connecting trackways in greater detail.
  • Hutted Camp North of Wilhelmshaven: A snow-dusted aerial view reveals both well-disciplined and poorly disciplined tracks, with melting roof-snow indicating occupied huts.
  • Problem Picture: Bloch 200 Fuselages: A puzzle photograph challenges readers to identify the objects, revealed upside-down as Bloch 200 fuselages at Istres-Le Tubé.
